Sample Model Number Tags
Model numbers can be made up of numbers (1005400, for example) or a combination of letters and numbers (LAT1000AAE). The model number will most likely appear on either a paper sticker or a metal plate. Your appliance's model number tag may look similar to the sample model number tags shown here (model number highlighted in yellow):
This water inlet valve should be located behind the lower kickplate panel in either the right or left corner. The attaching solenoids on the valve open and close according to the desired amount of water needed. This valve has a 3/8" inlet and comes with the mounting bracket.
How Buying OEM Parts Can Save You Time and Money
Why buy the real thing?
OEM stands for Original Equipment Manufacturer. Simply put, this means that the company who made your appliance is also supplying the replacement part for it.
Replacing your General Electric Dishwasher Dishwasher Water Inlet Valve
Troubleshooting
This part fixes the following symptoms:
Leaking | Will not fill with water | Not cleaning dishes properly | Not draining
This part works with the following products:
Dishwasher.
Part# WD15X10003 replaces these:
AP2039343, 785330, WD15X10003, 165D5792G001
Customer Reviews
Average Rating:
★★★★★
★★★★★
15 Reviews
4.7
Filter By Rating:
5 Stars
11
4 Stars
3
3 Stars
1
2 Stars
0
1 Star
0
Sort by:
< Prev
1
2
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing reviews that matched. Try using some different or simpler keywords.
★★★★★
★★★★★
Glenn R - October 29, 2021
Verified Purchase
Easy fix
New part. Seems to be working great.
★★★★★
★★★★★
Eugene G - October 30, 2018
Verified Purchase
Worked as expected.
Part arrived fast and fit as the photo showed. Configuration slightly different than mine but all connections worked fine.
★★★★★
★★★★★
Steve P - June 21, 2019
Verified Purchase
Exact replacement part
Easy repair job with exact replacement part thanks again!
★★★★★
★★★★★
Greg L - September 5, 2019
Verified Purchase
Easy install worked perfectly
Back in business ????
★★★★★
★★★★★
Tobie W - March 10, 2018
Verified Purchase
Easy repair.
Right part and fit just like it was suppose to. Thank you. Easy repair.
★★★★★
★★★★★
John L - August 3, 2018
Verified Purchase
Replacement of water inlet valve
The part was easy to install, following which the dishwasher ran perfectly
★★★★★
★★★★★
Stephen B - June 1, 2018
Verified Purchase
Easy quick fix
Even having to work in a tight space the repair was simple. Took about 5 minutes to install the new part. Getting the old one off was a bit more difficult but straight forward
★★★★★
★★★★★
Nick S - December 10, 2019
Verified Purchase
Easy
Part fit and was an easy install. Water was not running through the dishwasher but everything else functioned fine. This part solved the problem.
★★★★★
★★★★★
Byron T - May 27, 2018
Verified Purchase
Easy repair saved the cost of replacing the dishwasher.
Part was an exact duplicate of original, plugged right in, and mounted like the original part. Thanks easy repair!
★★★★★
★★★★★
Robb H - May 29, 2018
Verified Purchase
Quick and Easy
Quick delivery and fast installation.
< Prev
1
2
Next >
Customer Repair Stories
Average Repair Rating: 3.5 / 5.0, 28 reviews.
What's this?
Sort by:
< Prev
1
2
3
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing installation instruction that matched.
No water in
Pulled washer out. Found water inlet valve in lower left. Shut off power and water. Replaced valve with new.
Everett from FREDERICKSBRG, VA
Difficulty Level:
Easy
Total Repair Time:
1- 2 hours
Tools:
Nutdriver, Pliers, Screw drivers
1 personfound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Difficult to install the mounting screws
Nut driver and philips screwdriver.
Edward from TUCKAHOE, NY
Difficulty Level:
Easy
Total Repair Time:
1- 2 hours
Tools:
Nutdriver, Screw drivers
1 personfound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Leaking at the valve
Just like the video and replaced it
Brian from DERRY, PA
Difficulty Level:
Really Easy
Total Repair Time:
30 - 60 mins
Tools:
Nutdriver, Pliers, Wrench (Adjustable), Wrench set
1 personfound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
The water valve went out
I took the old one off and replaced it with the new one, which fir perfectly.
Paul from Terra Ceia, FL
Difficulty Level:
A Bit Difficult
Total Repair Time:
30 - 60 mins
Tools:
Pliers, Socket set, Wrench set
3 of 5 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Did not have water flowing into dishwasher
I removed the old valve with wrench and Philips screw driver.Unscrewed the mounting plate and water hose. When I went to replace the new water inlet valve, I found that there was a mismatch on the screw holes for the new mounting plate. Different screw threads. I tried to find screws that would fit, but didn't have any.So I manged to make
... Read more the old screws re-thread themselves and hold the plate in place. I then attached the water hose and started the dishwasher up. Make sure to power off the unit then power it back on to clear and reset the programming. Works great now.
Read less
selleck from kingston, NY
Difficulty Level:
A Bit Difficult
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers, Wrench (Adjustable), Wrench set
0 of 1 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Water inlet valve was leaking due to crack
After removing the front panels, I removed two screws holding the valve in place. I turned off the water supply and removed the water line, unclipped the hose clamps and took the faulty valve out. I then reversed the above steps and turned the water back on. NO leak. Very easy to do andthe repair took ~20 minutes to complete.
Carl from Pagosa Springs, CO
Difficulty Level:
Really Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver, Pliers, Wrench set
2 of 5 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Dishwasher was not filling with water or cycling.
In order to access the fill valve, dishwasher had to be removed from under countertop. Disconnected water supply line and drain hose under sink. Unplugged unit and removed 2 screws holding unit to countertop. I was then able to pull unit out and replace valve. After reinstallation, the same problem existed. Further research pointed to the
... Read more control module, approx. $100.00 or the motor, approx. $250.00 - $300.00. I than began looking at new dishwashers, but I did email GE with the problem. They suggested I use citric acid or vinegar in hot water, pour into right rear portion of tub and wait 1/2 hour. After doing that, the dishwasher worked perfectly.
Read less
Jeffrey from Punta Gorda, FL
Difficulty Level:
A Bit Difficult
Total Repair Time:
30 - 60 mins
Tools:
Screw drivers, Wrench set
41 of 46 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Plastic part of inlet valve cracked
Hired my neighbor, who is a plumber.
Barbara from Georgetown, CO
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Screw drivers, Wrench (Adjustable)
3 of 5 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Water Inlet Valve was leaking on dishwasher.
I replaced the entire Water Inlet Valve. The part was perfect and fixed the problem. The only difficulty was the brass elbow connection that connects to the incoming water line had plumbing putting that connected it to the old Water Inlet Valve. I had to get a couple of large adjustable wrenches to take it off. I needed it as I didn't wan
... Read moret to buy another one. I was thankful that I had some extra plumbing putty on hand to seal the threads when I put the brass elbow back on the new Water Inlet Valve. That saved me a trip to the hardware story. All in all, I'm very pleased that I was able to fix this myself. I'm not exactly a Mr. Fixit, so this was a good experience.
Read less
Israel from Covert, MI
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Pliers, Screw drivers, Wrench (Adjustable)
1 of 4 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Replace valve
Unscrew supply tube and angle nut from old valve. Disconnect tube from valve. Install new valve. Obtain new crimp seal for water supply tube. Use Teflon tape. Reconnect water tube to valve.
James from Hartsel, CO
Difficulty Level:
A Bit Difficult
Total Repair Time:
30 - 60 mins
Tools:
Pliers, Socket set, Wrench (Adjustable), Wrench set
12 of 13 peoplefound this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
< Prev
1
2
3
Next >
Questions and Answers
Ask our experts a question about this part and we'll get back to you as soon as possible!
12 questions answered by our experts.
Sort by:
< Prev
1
2
Next >
Search filter:
Clear Filter
Your search term must have 3 or more characters.
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
LINDA
August 14, 2017
I have a the GE dishwasher model# gsd3400g00ww (serial# md848018b). It is 15 years old. It is not filling up with water all the way. I think my inlet water valve is clogged up. To keep from replacing it at this time: 1) can i, and is there, any type of solution that i can run through this valve to clean it out without having to remove the valve from the washer? 2) if the valve has to be removed to clean it out, what is the best solution that i can make or buy to do the job easily? 3) what is it that usually clogs up this valve and or stops it from working? I am trying to not have to buy a new $55.00 valve. Please respond as soon as possible. Thank you very much.
For model number GSD3400G00WW
Hi Linda,
Thank you for your inquiry. If your washer is not filling up with water, there are a few parts that you may have to look at. The water inlet valve is one of them, but you may also have to look at the drain solenoid kit, the motor and pump kit, the float switch and the sump housing. In regards to the water inlet valve, there really is no solution that you can use to clean it, however, there are screens on the valve where the hoses connect to where sediment and water particles build up. You may want to remove the hoses from the valve to clean them to see if this will fix the issue. I hope this helps with the repair. Thank you and have a great day!
11 people found this helpful.
Was this helpful?
Thank you for voting!
Jeff
December 19, 2018
My Hotpoint dishwasher fills with water, but the drain activates immediately and drains all water so the is no water during any cycles. I've read it could be a bad timer, but i can't find a timer part listed. Would this part fix the problem?
For model number hda2000g00ww
Hello Jeff, thank you for your question. There are a few parts we would recommend testing. You should test the float switch PartSelect Number: PS260235 and the drain solenoid Part Number: PS260117. If those parts are tested and are functioning correctly the issue could be the timer PartSelect Number: PS260202. I hope this helps.
1 person found this helpful.
Was this helpful?
Thank you for voting!
Kevin
March 15, 2019
How to replace the rubber flow line comming off of the inlet valve. Where does it connect to.
For model number Gsd550
Hi Kevin,
Thank you for your question. There is a video listed with the water inlet valve on our website that you may reference on how to install it. I hope this helps. Thank you and have a great day!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Dean
May 15, 2019
Filling up sometimes when shut off.
For model number Gld5900n00cc
Hi Dean,
Thank you for your question. The issue is likely the water inlet valve. The screens on the valve are either clogged with debris and they need to be cleaned or a component in the water inlet valve has failed and it will need to be replaced. I hope this helps. Thank you and have a great day!
1 person found this helpful.
Was this helpful?
Thank you for voting!
Walter
February 2, 2022
My appliance drains but still leave's water in drain filter.
appliance Does not seem to clean top rack items as good as it used to.
can you give me some idea what to look for. I pulled filter cover and that is where water is standing. Thank you.
For model number GSD20000f01wh
Hello Walter, thank you for your question. We have researched the model you have provided, and we would suggest the Motor and Pump Kit, part number PS260801. If you need help placing an order, our customer service is open 7 days a week. Please feel free to give us a call. We look forward to hearing from you!
Hello Bob, thank you for contacting us, In order for us to locate the correct parts and repair information we will require the model number of the unit. Once you have located the model number please feel free to resubmit the question and we will be happy to help you. Look forward to hearing from you!
Was this helpful?
Thank you for voting!
Fernando
December 8, 2017
I am looking for a water inlet valve for my GE quiet power 3. The model # is gld4500n10bb and serial # is tr788284b. Please let me know if you have available part for my dishwasher. Thank you in advance.
For model number GLD4500N10BB
Hello Fernando, Thank you for contacting us. I have researched the model you have provided and have found the part you’re looking for is PartSelect Number: PS259368. Hope this helps!
Was this helpful?
Thank you for voting!
Richard
January 12, 2018
Dont have 110v at water solenoid valve. Float swich ok
For model number GSD2000GOOBB
Hi Richard,
Thank you for your question. If the water inlet is not working correctly, then you will need to replace it. I hope this helps. Thank you and have a great day!
Was this helpful?
Thank you for voting!
Dakota
December 18, 2018
I installed a new inlet valve and it immediately blew out. Is it a defective part or do i need to check something else?
For model number GSD2200G00WW
Hi Dakota,
Thank you for your question. It may be defective or the water pressure going into it is too high. That is something you will need to check. I hope this helps. Thank you and have a great day!
Was this helpful?
Thank you for voting!
ADRIAN
August 13, 2019
I believe the inlet valve is a problem. When the water is on and electric is off, the water continues to fill and overflow the sump. Would there be material causing the valve to not close in the water line to cause this or does there need to be electric power to this valve to be in the off condition.
For model number GLD5600N10BB general electric
Hello Adrian, thank you for writing. Power would have to be supplied for it to work correctly. It sounds as though the Water Inlet Valve is faulty. This part number PS259368 is the correct replacement for your model. You may also want to consider replacing the Flood Switch part number PS958959 for your model to fix this. I hope this helps and good luck with your repair!
Was this helpful?
Thank you for voting!
< Prev
1
2
Next >
✖
Ask a Question
Ask our experts a question on this part and we'll respond as soon as we can.
