DLE0442W (DLE0442W /01) LG Dryer - Overview

Sections of the DLE0442W

[Viewing 3 of 3]
Keep searches simple, eg. "belt" or "pump".
4 PACK ROLLER ASSEMBLY – Part Number: 4581EL2002L
4 PACK ROLLER ASSEMBLY
★★★★★
★★★★★
(71)
PartSelect #: PS17269866
Manufacturer #: 4581EL2002L
This part is sold individually. The drum support roller is found in your dryer. It is used to hold the drum in place in the cabinet while letting the drum rotate on the support rollers. It is recommen...
$135.77
  In Stock
Dryer Lint Filter – Part Number: 5231EL1003B
Dryer Lint Filter
★★★★★
★★★★★
(63)
PartSelect #: PS3527578
Manufacturer #: 5231EL1003B
The lint filter in your dryer is used to collect lint as it passes through the dryer vent. If you notice that your dryer is not providing enough heat, or if it takes too long to dry, you may need to r...
$50.03
  In Stock
Thermal Fuse – Part Number: 6931EL3003D
Thermal Fuse
★★★★★
★★★★★
(24)
PartSelect #: PS3530485
Manufacturer #: 6931EL3003D
This thermal fuse acts as a high-limit thermostat, and shuts off the heating element when the dryer overheats by cutting off power to the dryer. If the thermal fuse has blown, the dryer will not start...
$17.89
  In Stock
Moisture Sensor – Part Number: 6500EL3001A
Moisture Sensor
★★★★★
★★★★★
(6)
PartSelect #: PS3529161
Manufacturer #: 6500EL3001A
The sensor controls the temperature in your dryer and will turn off once your clothes have reached the desired dryness level. If you notice that your dryer is not giving off enough heat to dry the clo...
$22.26
  In Stock
Dryer Drum Belt – Part Number: 4400EL2001F
Dryer Drum Belt
★★★★★
★★★★★
(8)
PartSelect #: PS11705916
Manufacturer #: 4400EL2001F
The belt wraps the length of the dryer drum, secured by a tension pulley and then loops around the motor pulley. If you find that the drum is not turning properly or at all while your dryer is in succ...
$25.89
  In Stock
Dryer Thermistor – Part Number: 6323EL2001B
Dryer Thermistor
★★★★★
★★★★★
(4)
PartSelect #: PS3529026
Manufacturer #: 6323EL2001B
This dryer thermistor temperature sensor helps monitor and regulate the temperature inside a dryer. This part includes the wire harness. If your dryer overheats, does not produce enough heat, or takes...
$70.77
  On Order
Blower Thermostat – Part Number: 6931EL3002M
Blower Thermostat
★★★★★
★★★★★
(7)
PartSelect #: PS8747887
Manufacturer #: 6931EL3002M
The thermostat is a part for your dryer, and it is roughly 1 inch long by roughly 1.5 inches wide. The purpose of the thermostat is to measure the temperature of the air inside your dryer drum. As the...
$45.88
  In Stock
Thermostat Assembly – Part Number: 6931EL3001E
Thermostat Assembly
PartSelect #: PS3530481
Manufacturer #: 6931EL3001E
The high limit thermostat on your dyer prevents your dryer from overheating. When the dryer heats up too much, the high limit thermostat will sense it and automatically shut off the heating element. I...
$34.22
  In Stock
Felt Seal – Part Number: 4036EL3001A
Felt Seal
★★★★★
★★★★★
(4)
PartSelect #: PS3522851
Manufacturer #: 4036EL3001A
This genuine OEM felt gasket provides a cushioned seal between the inner tub of your electric dryer and the rear panel. It prevents your clothes from getting snagged and helps in heat retention. You w...
$33.87
  In Stock
Locker Assembly – Part Number: 4027EL1001A
Locker Assembly
★★★★★
★★★★★
(6)
PartSelect #: PS3522843
Manufacturer #: 4027EL1001A
$31.45
  In Stock
Pulley,Idle – Part Number: 4560EL3001A
Pulley,Idle
★★★★★
★★★★★
(5)
PartSelect #: PS3523032
Manufacturer #: 4560EL3001A
$23.35
  In Stock
Leg – Part Number: 4778EL3001B
Leg
★★★★★
★★★★★
(1)
PartSelect #: PS3523560
Manufacturer #: 4778EL3001B
This plastic adjustable dryer leg is used to support the weight and adjust the height of your dryer to keep it level. To install the leg, tip the dryer back and screw it into the bottom of your dryer ...
$10.94
  In Stock

Questions And Answers for DLE0442W

Ask our experts a question about this model and we'll get back to you as soon as possible!

3 questions answered by our experts.
Sort by:
  • 1
Sorry, we couldn't find any existing answers that matched.Try using some different or simpler keywords, or submit your new question by using the "Ask a Question" button above!
Donald
February 13, 2020
How many drum rollers are on this unit
For model number DLE0442W
PartSelect logo
Hello Donald, Thank you for the question. This model has a total of 4 drum rollers, Part #: PS. Two in the back and two int he front. We hope this helps.

1 person found this helpful.

Was this helpful?
Thank you for voting!
Related Parts:
Bobby
5 days ago
How to find the heat element to check it
For model number DLE0442W
PartSelect logo
Hello Bobby, thank you for your question. The heater Assembly is PS3527788. We have a video for a similar model that should help you. Good luck with your repair.

Was this helpful?
Thank you for voting!
Jim
January 14, 2020
This dryer is 12 years old, does the heating element lose strength over the years?. the dryer still heats but it takes a long time, we keep the screen clean and there does not seem to be a blockage in vent to the outside,are there other areas where blockage might occur? thanks jim
For model number DLE0442W
PartSelect logo
Hello Jim, Thank you for your question. Our sources suggest replacing the temperature sensor under part PS3529161 for your model to fix the dryers issues, as we do not think it is because of a blockage issue if the screen is kept clean and there is no visible blockage in the vent itself. We hope this helps.

Was this helpful?
Thank you for voting!
Related Parts:
  • 1

Common Symptoms of the DLE0442W

[Viewing 5 of 5]
Noisy
Fixed by
these parts
Fixing Fixing
Show All
Not Heating
Fixed by
these parts
Fixing Fixing Fixing
Show All
Door won’t close
Fixed by
these parts
Fixing Fixing Fixing
Show All
Drum Not Spinning
Fixed by
these parts
Fixing
Show All
Marks left on clothes
Fixed by
these parts
Fixing
Show All
Keep searches simple. Use keywords, e.g. "leaking", "pump", "broken" or "fit".
Dryer making a thumping and squealing noise when running
Had to replace front drum support rollers. Removed screws underneath top in back that held bracket that keeps top in place. Slid top towards rear and lifted up. Removed 4 screws that hold plastic front panel in place (inside..2 on each corner) Unplugged front panel electric plugs to remove panel. Opened door..removed 2 screws at bottom of door opening. Removed screws on top of front panel. Unplugged door switch plug. Removed front panel. Removed right front roller with 9/16th wrench for nut. Adjustable for back of stud. Lifted up on drum to get roller out. Reversed to install. Left roller a bit harder to get to stud. Removed and installed same as right side. Did not attempt to replace rear rollers. Have them if needed but very much more involved to replace.
Parts Used:
4 PACK ROLLER ASSEMBLY
  • Mark from WAVERLY, OH
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Screw drivers, Wrench (Adjustable), Wrench set
92 of 117 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Dryer would run with no heat
I actually went to mr fix it on u tube. Great instruction on how to take dryer apart. First I unplugged the dryer. I found I could reach the heating system by removing the lint tube in the back of the dryer. I put my I phone with the light on inside the back of the dryer and tested the connections to see if all were working. The thermal fuse was not working. I removed the two wires , red on top and white on the bottom. Then used a small Phillips screwdriver to remove the two mounting screws and removed the fuse. I then used a vacuum to clear any lint from the back of the dryer and inside the dryer. This took me about an hour and a half. I did it this way because I did not want to disassemble the entire dryer to get to the components. I received the fuse in 3 days and tested it. It was fine. I then put it in the dryer screwed it in place, connected the wires. Replaced the lint tube. This took about 10 minutes. Dryer is running great.
Parts Used:
Thermal Fuse
  • Richard from ORMOND BEACH, FL
  • Difficulty Level:
    Easy
  • Total Repair Time:
    30 - 60 mins
  • Tools:
    Screw drivers
72 of 82 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
Screeching during operation
Found disassembly video and watched several times. Suspected that one of the drum wheels had seized up. Found extreme volume of lint and hair inside unit as well as a dryer sheet melted on top of heating unit. Front left drum wheel was worn down from lint and hair jamming its movement. Video made it easy, not a really complicated piece of machinery. Replaced all 4 wheels due to normal wear on other three. Wanted to be sure drum evenly balanced on all 4. Parts came quickly and were easy to install. My sister and I did this together. Would not recommend doing it alone. Took time to vac and wipe down entire unit. Now it runs so quiet we have to look to see if it is operating. Got a brand new machine out of it, saved a couple of hundred dollars in repair bills, and found 11 cents inside the machine. For your own piece of mind, if you have had your dryer for several years, you need to open it up and clean it out. Its not hard... added note, we are both in our 60's... so if we can do it so can you.... Such a feeling of accomplishment, can't buy that in a store....
Parts Used:
4 PACK ROLLER ASSEMBLY
  • CAROL from NAMPA, ID
  • Difficulty Level:
    Really Easy
  • Total Repair Time:
    More than 2 hours
  • Tools:
    Pliers, Screw drivers
41 of 59 people found this instruction helpful.
